Shimpo NVS-07 Pugmill Mixer, Stainless Steel

The NVS-07 De-Airing Pugmill Mixer features a powerful 1HP Motor for mixing and extruding, it is all stainless steel, giant hopper and good size nozzle (which also is compatible with the add on dies), the clay cutter and roller shelf is included and very easy access for cleaning and maintenance. Also a great feature is the dual safety system that includes a limit switch and overload system.

FEATURES:

TECHNICAL SPECIFICATIONS:

All stainless steel
Dual safety system; limit switch and overload system
Powerful 1 HP Motor; mixing and extruding
Includes clay cut-off wire and clay receiving table
Roller shelf included
Oil-free vacuum pump system
Large hopper and nozzle
Max batch capacity 45 lbs
Maintenance access; easy access for cleaning and maintenance

Motor: 1 HP, gear driven

Power Source: 115 V / 60 Hz

Max Batch Capacity: 45 lbs

Hopper Size: 8 ½" x 11 ½"

Vacuum Pump System: Air vacuum pump system (oil-free), vacuums in same chamber as clay mixing

Nozzle Diameter: 3 ½" nozzle

Dimensions: 35" x 17" x 33" (47" long with roller shelf extended)

Weight: 310 lbs

Ship Weight: 380 lbs
